Magnetic latching solenoids use a single electrical pulse to switch and maintain position without continuous power. They deliver energy-saving performance ideal for long-hold locking mechanisms and security systems. A magnetic latching solenoid is equipped with a permanent magnet inside the housing that keeps the plunger in position magnetically when under no other force.
| Parameter | Specification |
|---|---|
| Standard Voltage | DC: 12V DC to 24V DC |
| Voltage Range | ±5% |
| Wire Insulation Class | Class F / Class H / 200℃ (IEC317-8) |
| Holding Force | 5 N – 20 N or according to the specific |
| Coil ID Range | 12 mm to 25 mm |
| Stroke | 15 mm |
| Coil Insulation | Class F / H (others on request) |
| Ambient Temperature | -20℃ to +70℃ |
